Details
- 19'' length
- 5/8 center
- 9.25 lbs.
Blades
Blade Width Measure near the center of the blade. | 2.50" |
Blade Thickness Measure near the center of the blade. | 0.250" |
Blade Length Measured diagonally from the corners of the blade | 19" |
Center Hole Size Many blades will have a round hole in the center of the blade and you will need to know its diameter. Blade Length 5 or 7 Point Star Center holes may be 5 or 7 point star shaped. 5 point star on blade7 point star on blade Square or Rectangular The MTD built blades on many walk behind lawn mowers have a 'bow-tie' hole. In this case the Oregon replacement blade will have a rectangular center hole which will fit on the bow-tie pattern on the blade adapter. Square or Rectangular hole on blade MTD Blades The MTD® built blades (Bolens, Cub Cadet, Troy-bilt, White, Yard Machine, and Yardman) may have a 6 point star. Oregon replacement blades will have a 'Y' shaped center hole which will fit exactly on the 6 point star on the blade spindle. 6 point star for MTD blades The two sizes of the 6 point star. If your blade spindle has a bolt and lock washer that holds the blade to the machine you would use the 11/16" star or 'Y' blade. blade spindle with bolt and lock washer. If your blade is secured with a large flange nut then you would use the 5/8" star or 'Y' blade. blade spindle with large flange nut | 5/8" |
OffSet (Sometimes referred to as offset): If you set the blade on a table this is the distance the center of the blade is above the table top (if any) when the cutting edges are flat on the table | 0 |
Air Lift Air lift is the distance the lift panel rises above the cutting edge. | 1" |
General
Color | Black |
Volume | 47.375 in3 |
Product UOM | Each |
Weight (with Packaging) | 3.135 Lb |
Product Height | 0.25 |
Product Length | 19" |
Product Width | 2.5 |
Packaged Length | 18.95" |
Packaged Width | 2.5" |
Packaged Height | 1" |
